Design No. 169

Apache

1909Int. Metre ClassAlfred Mylne

Design 169 represents an International Metre Class yacht conceived by Alfred Mylne. The design yielded at least one completed yacht, Apache, built in 1909. The archive retains eleven drawings associated with this design. Further details regarding the original client, builder, and technical specifications remain incomplete in the available records.

Original Drawings · 11 sheets

Purchase high-res drawings

Dimensions

LOA10.2 m / 34 ft
LOD9.5 m / 31 ft
LWL6.2 m / 20 ft
Beam1.9 m / 6 ft
Draft1.2 m / 4 ft
Sail Area51.933 m²

Yachts in the Register · 1

Builder

McAllister, Dumbarton

Built Apache (1909)

sandpoint-marina.co.uk

[AI-generated] McAllister was a Clyde boatbuilding firm operating from the Sandpoint Marina area of Dumbarton through the 20th century. The yard serviced Clyde yacht fleets; local records associate the yard with Pat Docherty. The facility evolved into the modern Sandpoint Marina, which continues as a professional boatyard offering lift-out and year-round storage. [Enrichment] McAllister was a Clyde boatbuilding firm operating from the Sandpoint Marina area of Dumbarton. The yard serviced Clyde yacht fleets through the 20th century; local records associate the yard with Pat Docherty.

Historical Context

The International Metre Class emerged as a significant racing category in the early 1900s, governed by the International Metre Rule. Alfred Mylne, established as a leading Scottish yacht designer, produced numerous designs across the Metre Classes during this period. Design 169 and the resulting yacht Apache date to 1909, a year of considerable activity in Mylne's design practice. The class represented a sophisticated category of racing yacht, requiring careful adherence to measurement rules whilst maximizing competitive performance. Mylne's involvement with the Metre Classes extended across multiple designs and demonstrated his understanding of both the technical and competitive aspects of this specialised racing category.
