Design No. 305
Ariadne
Design 305 represents a single screw motor yacht conceived by Alfred Mylne. The design produced at least one built yacht, Ariadne, launched in 1925. The archive preserves 26 drawings associated with this design, providing insight into Mylne's approach to motor yacht development during the interwar period. Complete technical specifications and construction details remain to be catalogued.
Original Drawings · 26 sheets
Lines Plan
Misc
Misc
Misc
Misc
Rigging Plan
Misc
Sail Plan
Misc
Structure
Misc
Structure
Structure
Lines Plan
Lines Plan
Sail Plan
Misc
Misc
Misc
Misc
Dimensions
Notes
Gilbert Isles Research Vessel
Yachts in the Register · 1
Builder
A. Robertson & Sons, Sandbank
Built Ariadne (1925)
[AI-generated] A. Robertson & Sons was a celebrated Scottish boatyard established in 1876 on Sandbank's Holy Loch shore, operating for 104 years until 1980. The yard became renowned for building early metre-class racing yachts and earned international prestige constructing two 12-metre America's Cup challengers—Sceptre (1958) and Sovereign (1964)—designed by David Boyd. Alfred Mylne's designs commenced there in 1900, including the Clyde class sloops Valmai and Susette, followed by five yachts for Edmund Nordheim. Over 482 vessels were built for clients ranging from wealthy Clyde racing enthusiasts to the Admiralty (23 Fairmile motor torpedo boats during World War II). Unable to compete with modern fibreglass production, the boatyard liquidated in 1980; the historic site was subsequently redeveloped into residential areas and Holy Loch Marina, though maritime operations continue under Leisure Ecosse ownership.
Historical Context
The 1920s witnessed significant evolution in yacht design as motor propulsion matured. While Mylne remained celebrated for his sailing yacht designs, the period saw growing demand for motor yachts among wealthy patrons. Single screw motor yachts offered practical advantages over sailing vessels for certain applications and owners. Mylne's concurrent work across both sailing and motor yacht commissions reflects the design profession's adaptation to changing client preferences and technological capability. The preservation of 26 drawings for Design 305 underscores the complexity of motor yacht development, requiring detailed engineering drawings beyond those typical for sailing craft.
